RDL RU-RN22

Mic/Line Bi-Directional Network Interface 2×2
Converts Two Mic/Line Inputs to Two Dante Channels with 4×4 Virtual Mixers
Converts Two Dante Channels to Line with Software Controlled Attenuation
XLR and Removable Terminal Block Available for Each Input and Output
Provides Functions of Audio Mixer and/or Distribution Amplifier
Control Settings over Network using RDL Console Software and 3rd Party Control Systems
Remote Controllable using Compatible RDL Remote Controls
Selectable Audio Compressor/Limiter and Filters
P48 Phantom Individually Selectable per Input with Gain-Dependent Auto-Disable
Input Gain Adjustable From 0 dB to 60 dB in 3.3 dB steps
Dante Audio Outputs Adjustable in 1 dB Steps 0 to -63 dB then OFF
Multicolor LED Indication of Audio Levels, Sync and Signal Presence
Operates at 48 kHz or 96 kHz Sample Rate with High Resolution 24 Bit A to D Conversion
Extremely Low Noise <-70 dB Below Operating Level at 60 dB (Max) Input Gain
Legendary RDL Analog Filtering Enhances Superb Audio Performance
Operation from PoE Power or External 24 Vdc

RDL EU-BTN21

Bluetooth Audio Input for Dante or AES67 Networked System
Bluetooth Stereo or Mono Sum Feeds Two Network Channels
Return Audio Talk Channel from Dante Network to Bluetooth-Connected Device
Intuitive Single Button Bluetooth Pairing with LED Status Indication
Bluetooth Functions are Controllable in RDL CONSOLE Software
Q-SYS Plug-In Available for Configuring in Q-SYS Environment
Controllable Functions Include Pairing/Un-pairing, Media Source Track Selection and Level
Bluetooth Track Title and Artist Data are Multicast on the Network to Compatible Devices
Customize the Module ID Name, Settings and Mono/Stereo Mode using RDL CONSOLE Software
White Faceplate Laminate is Installed, Field-Replaceable Black Laminate Included
European 45 mm x 45 mm Chassis Fits in a Standard 60 mm Deep EU Junction Box
Module is PoE Powered
