- PHYSICAL
- Color Black or White
- Material Aluminum Housing with Stainless Steel
- Dimensions (H × W × D)* 38.7 x 9.4 x 10.4in (983 x 239 x 264mm)
- Net Weight* 70lbs (32kg) Shipping Weight* 85lbs (36kg)
- PERFORMANCE
- Max SPL (Peak 1m), unadapted1 143dB
- Operating Range2 (-10db) 65Hz – 20kHz
- Nominal Beamwidth3 120 ° Horizontal x Adaptive Vertical
- CONFIGURATION
- LF Transducer, Loading 6 x 6 in cone, 1.7 in voice coil vented (w/ CSA)
- HF Transducer, Loading 30 x 19mm dome tweeter, horn loaded
- Operating Mode 6 x LF, 30 x HF
- Amplifier Channels Signal Processing DSP with EAW Focusing™ and Adaptive Performance™
- ELECTRICAL
- Input Type Electronically Balanced Max Input Level 25dBu Impedance 20kOhm (balanced)
- Wiring 2x XLRF, Pin 1 chassis, pin 2+, pin 3- 2x Separate Loop through XLRM (for analog signal only)
- Dry Contact Interface Input overide, preset recall, fault status Separate loop through & 6x pass through pins
- Voltage 5V nominal, 12V maximum Power Draw 600W Input & Loop Type Analog/AES/Dante®
- Amplifier Type Class D Amplifier 6 x 150W LF 30 x 75W HFMax Output LF / HF (Peak)
- Driver Protection Integral DSP Limiting
- AC Mains (nominal)
- Connector Neutrik PowerCON® True1 Top Input 100V to 240V Frequency 50Hz to 60Hz
- POWER CONSUMPTION
- Full 600W 1/3rd 380W 1/8th 180W Idle 120W
